| HARDWARE FEATURES | WI-SG124D |
| Standards | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p |
| Interface | 24 100/1000Mbps RJ45 Ports |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
| 100BASE-TX/1000Base-T: UTP category 5, 5e, 6 or above cable (maximum 100m) | |
| 1000BASE-X: MMF, SMF 1000Base-L X:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m) | |
| DIP Switch | Default/VLAN/CCTV |
| Fan Quantity | Fanless |
| Exchange Capacity | 48G |
| Packet Forwarding Rate | 35.7Mpps |
| Mac Address Table | 8K |
| Power Adapter | AC IN: 110-240V |
| Packet Buffer Memory | 12Mb |
| Jumbo Frame | 10240 Bytes |
| Port VLAN | Yes |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Package Dimension | 380×215×95 mm |
| Switch Dimension | 305×140×45 mm |
| Gross Weight | 1.67kg |
| Net Weight | 1.17kg |
| Package Contents | 1 × Gigabit Switch |
| 1 × Power Cord | |
| 1 × Quick Installation Guide | |
| Working Temperature | -10℃～55℃ |
| Storage Temperature | -40℃～70℃ |
| Working Humidity | 10%～90% RH |
| non-condensing | |
| Storage Humidity | 5%～90% RH non-condensing |
| Warranty | 3 Years |
● 24 100/1000Mbps RJ45 Ethernet ports
● Plug and play, zero configuration
● Supports desktop or wall mount replacement
● Smart DIP Switch: Port VLAN mode, video priority mode
● Energy efficient design compliant with IEEE802.3az
● Silent operation ideal for noise sensitive environment
